Este un instrument util pentru a fi informat de amplasarea radarelor pe sosele precum si informatii despre conditiile de trafic. Pentru functionarea corecte va recomandam sa apelati pentru instalare la o firma / persoana autorizata (specializate in instalarea acestor aparate). Statia are nevoie de o antena pentru a putea functiona. Alegerea si montarea corespunzatoare a antenei determina functionarea la parametrii maximi ai sistemului.
Va recomandam sa alegeti una din modelele:
6-0082 -fixare prin gaurire
6-0080 + 6-0077 -fixare magnetica
6-0080 + 6-0075 - fixare mecanica
6-0080 +
6-013410614 - fixare mecanica
precum si alte modele din sectiunea :
FEATURES
1. AM/FM Mode For Selection
2. Signal Strength Indication.
3. Full 4 Watts RF power
4. RF Gain Control
5. ANL-OFF Selector
6. LOC-DX Selector
7. ASQ Function
8. Emergency Channel 9/19
9. Squelch Control
10. Scan Function(automatic search of busy channels)
11. Memory channel(M1-M4) Selection
12. PA Function
13. LED back-light
14. No License Required.
Technical Specification
GENERAL
Frequency range 25.615-28.305MHz
Frequency control P.L.L
Channels 40AM/FM
Power supply 13.8Vdc±15%
Operating temperature 10+55
Size 160 (W)×140D×44mm (H)
TRANSMITTER
RF power output 4W(at 13.8Vdc)
Carrier freq. error <±800Hz
Modulation 60% to 70% @ 8mV 1 kHz audio tone input (AM)
80% to 90% @20mV 1 kHz audio tone input (AM)
1.5 KHz @8 mV 1 kHz audio tone input (FM)
2 KHz Hz @50 mV 1 kHz audio tone input (FM)
Spurious emissions 60dBc(typical)
RECEIVER
Reference sensitivity -118dBm @ 12dB SINAD (FM)
-107dBm @ 12dB SINAD (AM)
Current consumption 180mA(stand-by)
System Double conversion with CPU controlled
Audio output 2.5w at 10% THD,16ohm loading
